Aluminium honeycomb panels
OSMAX panels, certified in Singapore and supplied here only by Two Nine Six O Trading. For façades, soffits, ceilings and fins: light enough for long spans and twisting forms, flat enough for the largest planes.
Two skins and a honeycomb
An OSMAX panel is a sandwich: two sheets of aluminium bonded to a core of hexagonal aluminium cells, the same geometry a bee uses to build strong with little material.
The result is a 20 mm panel that stays flat across large spans, resists wind pressure and puts very little dead load on the structure behind it. It can be formed into curves, folds and the twisted units of a decorative fin, and the aluminium is 100% recyclable.
OSMAX (北京欧森迈科技发展有限公司) was founded in Beijing and has made architectural panels for more than twenty years, for stadiums, museums, airports and headquarters across China. Two Nine Six O Trading is its exclusive distributor in Singapore.
- 20 mm
- panel thickness certified in Singapore
- A2-s1, d0
- fire classification to EN 13501-1
- 100%
- recyclable aluminium
Ranges and finishes
- Anodised aluminium honeycomb panelsExternal façades, curtain walls, cladding
- Anodised and custom finish panelsUV and corrosion resistant
- Integrated façade componentsWith glazing, composite and metal
- Interior cladding and ceiling panelsCommercial, hospitality, institutional
Pick a finish to see it on the panel
Colours on screen are a guide. Final finishes are approved against physical samples, which we send on request.
Tested, listed, built
The Singapore certificates for the OSMAX 20 mm panel are held by Two Nine Six O Trading in its own name. Copies come with every submission.
- Fire
- EN 13501-1:2018
- Class A2-s1, d0
- KAS report J250915005-1
- Product listing
- TÜV Rheinland Singapore
- Product Listing Scheme
- CoC PLS TRSG-2-25023
- Valid to November 2030
- Green label
- Singapore Green Building Product
- SGBP 6196, Leader (4 ticks)
- Valid to December 2027
- Built with OSMAX
- Tencent Beijing Headquarters
- ByteDance Houhai Center
- Shanghai Grand Opera House
- Chongqing Science Hall
- Hefei Science and Technology Museum
- Wuhan Wuhuan Sports Center
- Zaozhuang Yiyun Airport
- Hangzhou Baolong City Plaza
- JD Southwest Headquarters
- Beijing JD Group Building
- Holland Flower Sea Only Love Theater
Landmark projects
Some of the buildings in China clad with OSMAX panels. Scroll to move through them.
Only Love Theater
ByteDance Houhai
Baolong Plaza
Wuhuan Sports
Built for the tropics
Strength without weight
- Honeycomb core between two aluminium skins
- High rigidity at low panel weight
- Flat across large-format spans
- Strong wind-pressure performance
- Forms curves, folds and twisted units
Made for sun, rain and salt air
- Anodised surface for long-term UV resistance
- Resists oxidation and corrosion
- Holds up to coastal, salt-laden air
- Finishes that keep their tone
Papers ready for submission
- EN 13501-1 Class A2-s1, d0
- TÜV Rheinland Singapore listing
- SGBP Leader, 4 ticks
- Test documents for specification
- Certificates held locally by T2960
A team in Tuas
- Specification advice
- Technical evaluation and drawing review
- In-house laboratory testing
- On-site inspection
- Applicator coordination and training
From drawing to site
OSMAX makes the panels in Wuhan. We handle everything on the Singapore side, from the first detail to the last inspection.
Design
- Specification adviceT2960
- Drawing reviewT2960
- Samples and finishT2960 + OSMAX
Submission
- Fire and listing papersT2960
- Value engineeringT2960
Supply
- Panel fabricationOSMAX, Wuhan
- 配送To your site
Site
- Applicator trainingT2960
- On-site inspectionT2960
Certified panels on siteOne local contact
Send us the detail. We reply with a panel proposal and samples.
