JDV 4.02 – Seismic vertical expansion joint for façades, wall and ceiling
The VEDA JDV 4.02 and JDV 4.02A are all-aluminium seismic vertical expansion joints for façades, walls, and ceilings. They provide an aesthetic and durable solution for demanding projects such as airports, train stations, malls, schools, and hospitals. Designed for embedded installation, the JDV 4.02 is a flat profile, while the JDV 4.02A is an angle profile. Both accommodate significant seismic and structural movements while maintaining a clean, architectural finish.
Key Highlights
- All-aluminium expansion joint system for façades, walls, and ceilings
- Seismic performance with large movement capacity
- Flat profile (JDV 4.02) and angle profile (JDV 4.02A) options
- Gap widths from 40 mm up to 200 mm
- Durable, aesthetic, and suitable for public and commercial buildings
- Embedded installation — instructions and video available on request
- Standard length: 3 m
Packaging
| Reference | Type | Gap up to (W) | Height (H) | Movement Capacity | Material | Length |
|---|---|---|---|---|---|---|
| JDV 4.02-040 to 4.02-200 | Flat | 40–200 mm | 15.7 mm | +25/-25 up to +100/-100 (depending on model) | Aluminium | 3 m |
| JDV 4.02A-040 A to 4.02A-200 A | Angle | 40–200 mm | 15.7 mm | +20/-20 up to +50/-50 (depending on model) | Aluminium | 3 m |
